Full Automatic Stop Cylinder Screen Press

Model JB-720A JB-900A JB-1020A Max. sheet size 720×520mm 920×620mm 1020×720mm Min. sheet size 350×270mm 350×270mm 560×350mm Max. printing size 720×500mm 900×600mm 1020×710mm Frame size 880×880mm 1070×1140mm 1140×1280mm Paper thickness 108 400 g/m2Registration precision 0.10mmGripper margin ≤ 10mmPrinting speed 1000-3600 sheets/hour 1000-3300 sheets/hour 1000-3000 sheets/hour Power of printing part 3P 380V 50/60Hz 9.36KW 3P 380V 50/60Hz 9.36KW 3P 380V 50/60Hz 14.61KW Total weight 3500kg 3800kg 5500kg Dimension 9400×2400×1600mm 9500×2650×1600mm 10000×2800×1600mm JB-A Series Full Automatic Stop Cylinder Screen Press adopts the classical “stop cylinder” technology, which ensure the precious printing registration at high speed performance. It is suitable for screen printing on various semi-rigid and flexible substrates such as paper, cardboard, soft PCB, film, ceramic, glass appliqué, and so on. It can be also used as a UV spot varnishing machine.
